16CH 16SATA HD NVR,H.265,16CH Realtime Playback,VSS Mobile APP,Support 4K HD,P2P

2019-5-15 13:58:38, Visits:
Product Model: NVR9116-AV
FOB Price: US$573.1-US$593.1
Min. Order: 1pc
Product Brand: IdeaCamera
OEM/ODM: Support
Warranty: 2 Years
Country of Origin: China
Certificate: CE,FCC,ROHS
PDF:

Inquire Now >

Model: NVR9116-AV

H.264 / H.265 Format, ONVIF 2.6.

IP input: 16ch@720/960/1080P/3.0/4.0MP/5.0MP/6.0MP @30fps.

Bandwidth: 128Mbps.

16SATA*8TB, 1 x E-SATA (DVD RW optional), Max 1~16ch real-time playback.

1 x VGA, 2 x HDMI output, Audio: 64ch in by RJ45, 1ch in by RCA, 1ch out by RCA.

ONVIF2.6, Multi-Protocols, Support P2P, Support Cloud Storage.

Built-in free DDNS, UPNP, 3G Dongle supported, Digital zoom, Mobile phone surveillance.

2 x RJ45, 2 x HDMI, 3 USB2.0, Power supply (AC 110~240V), remote, mouse.

Support 4K HD output, supportGB28181.

Mobile APP: (VSS Mobile)



Offer services:

Offer 2-years product warranties.

Logistics convenient.

OEM/ODM.

CCC/CE/FCC Certified.

Strict product quality control.

Lower price.

6-8 working day per order.



Applications:

This is the best product of safety field. It and CCTV cameracablepower supplydisplayetc. Constitute a complete security system. Tts application is more extensive. Such as homesfactorieshighwaysoffice buildinggardencommunity, or a large public places, etc.


Model

NVR9116-AV

NVR9132-AV

NVR9164-AV

OS

Embedded Linux

Video&Audio input

Bidirectional Talk

1CH, RCA (Line   in,2Vp-p,1Kohms)

Incoming bandwidth

128Mbps

200Mbps

256Mbps

IPC   Input

16CH

32CH

64CH

Video&Audio output

VGA

1CH,1920×1080,1280×1024,1280×720,1024×768

HDMI

Standard 2.0

3840×21601920×1080,1280×1024,1280×720,1024×768

Audio Output

1CH, RCA (Line   out,2Vp-p,300ohms)

Video&Audio   encoding

Audio Compression

G.711A

Audio Bit Rate

64Kbps

Video&Audio   decoding

IP channel Resolution

Main stream: Up to   3264x2448
  Auxiliary stream: D1

Video decoding

H.265(Main   Profile@L5.0 High-tie)/H.264(Up to High Profile@Level5.0)

Audio decoding

G.711A/G.726

Synchronous Playback

Up to 16CH

Up to 32CH

Up to 32CH

Decoding Ability

161080P@30FPS

161080P@30FPS

161080P@30FPS

Other Function

Bidirectional Talk

Two-way voice intercom   function

Motion Detection

Zones: 396(22*18),   Sensitivity: 1~6 (level 6 is highest)

Picture Capture

Support JPEG Capture

HDD Interface

SATA

16 SATA Interfaces

eSATA

1 eSATA Interface

Max Capacity

Unlimited

External Interface

Network Interface

2 RJ45 10M/100M/1000M   self-adaptive Ethernet interfaces

USB

3 USB 2.0 Interfaces

Alarm Input

16CH

 Open/Closed Relay

Alarm Output

4CH

NO/NC

RS-232

1 RS-232 interface

RS-485

1 RS-485 interface

Structure

Size

3U,437*483*143mm

Weight

18Kg (without HDD)

Installation

Rack installation,   Desktop installation

General

Power Supply

110V~220V±10%, 47Hz63Hz

Working Temperature

0℃--55℃

Working Humidity

10--90

Consumption

30W (without HDD)
