2MP Waterproof IR Bullet 4-in-1 Camera with OSD Menu,Support UTC Control

2018/9/28 15:44:25, Visits:
Product Model: RC-BF75PAHD-3E
FOB Price: US$5.14 - US$16.14
Min. Order: 1pc
Product Brand: IdeaCamera
OEM/ODM: Support
Warranty: 2 Years
Country of Origin: China
Certificate: CE,FCC,ROHS
PDF:

Inquire Now >

Model Number: RC-BF75PAHD-3E

Main Features:

White casing with strong bracket

42pcs 5 IR LEDs(35M IR Distance).

Metal+ glass strong lens.

3MP 3.6mm HD Fixed Lens (2.8mm,4mm,6mm,8mm optional).

BNC Interface Video Cable (With OSD Menu).



Key specifications:

Image sensor (SOI F22+Fullhan V30E DSP)

Output AHD/TVI/CVI/CVBS, Effective resolution is up to 1920*1080/960H.

OSD menu supports 12 different languages.

Strong light inhibition/privacy protection.

BLC/DPC, 2D noise reduction function.

OSD function (mirror image, color/ white-black, PAL/NTSC).

UTC Function (Working by Hybrid DVRs).

AGC type, day-night effect is distinct, various day-night modes can be switched by OSD menu

With D-WDR.

Support UTC, 4-in-1, switched by OSD, Enhancement adjustment supported by OSD.

Power 600W&Video2KVdual-lightning protection design, OSP antioxidant PCB, size 32*38

Dual-border.



Production Advantages:

Offer 2-years product warranties.

Logistics convenient.

OEM/ODM.

CCC/CE/FCC Certified.

Strict product quality control.

Efficiently working with almost HD Hybrid DVRs.

Lower price.

6-8 working day per order.



Production applications:

This is the best product of safety field. It and hard disk video recorderscablepower supplydisplayetc. Constitute a complete security system. Tts application is more extensive. Such as homesfactorieshighwaysoffice buildinggardencommunity, or a large public places, etc.


escriptions2MP HD AHD Camera Modul
Sensor1/2.9 inch SOI F22+Fullhan V30E sensor
Video Resolution1920(H)*1080(V)
Effective pixelsApprox.2.07M pixels
Signal systemPAL/NTSC(Switch by OSD Menu)

Minimum Illumination
color:0.01Lux@(F1.2,AGC ON),0Lux with IR

Black & White:0.001Lux@(F1.2,AGC ON),0Lux with IR
S/N Ratio≥41dB
BLCAUTO
Shutter1/50(1/60) seconds to 1/50,000 seconds
AWBAUTO
IR Control Input VoltageOFF(DC OV)/ ON:DC 3V-8V
Video OutputAHD/TVI/CVI/CVBS
OSD menu(12)English/Simplified Chinese/Traditional Chinese/German/French/Italian/Spanish/Polish/Portuguese/Dutch/Turlish
Video record occupation1min≈24mb (4mm lens)
Working VoltageDC 12V/76mA±6mA(wide voltage 9v-18v)
D/N FunctionExternal(Default)/Auto/Color/White&Black (Switch by OSD Menu)
Synchronous Modeinter-sync
Temperature and Humidity- 20 ℃ ~ 50 ℃, humidity is less than 90% (no condensation)
SizeStandard 32*32 positioning hole, compatible with 38*38 hole
Accessories AHD Camera Manual, warranty card/certification, 1 dryer
