2MP IP Camera,H.265 IR Waterproof,Internal POE with Audio in,VSS Mobile App,Support face detection

2019-9-18 14:11:20, Visits:
Product Model: RC-BF75P-2MPO-P-A
FOB Price: US$24.26-US$26.26
Min. Order: 1pc
Product Brand: IdeaCamera
OEM/ODM: Support
Warranty: 2 Years
Country of Origin: China
Certificate: CE,FCC,ROHS
PDF:

Inquire Now >

Model: RC-BF75P-2MPO-P-A

Key features:

3.0-megapixel 3.6mm HD Fixed Lens (6,8,12mm optional).

42pieces IR LEDs, 40 meters of IR distance.

White metal casing with strong bracket.

Normal network video cable with waterproof sleeve.

Internal POE with audio in.



Product characteristics:

1/2.9” CMOS Sensor (OV2735+313E DSP).

Support H.264/H.265/H.265+ Video compression.

Mobile APP Name: (VSS Mobile).

Computer operation client (IMS300).

Standard 38*38 single board, Easy to install CCTV Camera.

Support IR-CUT (Day and night auto switch).

Max video resolution: 1920*1080@25/30fps.

Support 1ch audio input, 1ch audio output, realize two-way phonetic dialogue.

Support 1ch alarm input.

Support 1 USB reserve interface.

Support 1ch CVBS output.

Support three-bit stream.

Support 3D noise reduction and digital WDR.

Support private network penetration and cross browser access.



Product Advantages:

Offer 2-years product warranties.

Logistics convenient.

OEM/ODM.

CCC/CE/FCC Certified.

Strict product quality control.

Efficiently working with almost NVR.

Lower price.

6-8 working day per order.



Product applications:

This is the best product of safety field. It and hard disk video recorderscablepower supplydisplayetc. Constitute a complete security system. Tts application is more extensive. Such as homesfactorieshighwaysoffice buildinggardencommunity, or a large public places, etc.


2MP   HD IP Module

 Model

RC-BF75P-2MPO-P-A

System Structure

DSP

Embedded RTOS Design DSP (313E)

 Sensor

1/2.9" CMOS SensorOV2735

Video Code

Video Code Standard

H.265/

H.264High Profile/Main Profile/

Base Line Profile/ MJPEG

H.265+/

H.264High Profile+/Main Profile+/

Base Line Profile+

Max Image Resolution

Main Stream1920*1080@25/30fps

Sub-stream1704*576@25/30fps

Sub-stream21280*720@25/30fps

Stream Transmission

Three-bit stream

Video Code Rate

32Kbps~8MKbps

Image Adjustment

Low Illumination

Color 0.01Lux@F1.2AGC ON);

Black&White 0.001Lux@F1.2AGC ON

Electronic Shutter

Auto1/25~1/10000

D&N Transformation

Color/D&N/Photosensitive   transformation/Mixed mode transformation

White Balance

Auto/Locked white balance/Daylight   lamp/Incandescent lamp/Florescent lamp/Manual

Digital Noise Reduction

Support 2D/3D digital noise reduction

WDR

Support digital WDR

Video Adjustment

Sharpness/Brightness/Saturation/Contrast   ratio/Chromaticity adjustable

Image Mode

Transparent/Real

Color Mode

Standard/Gorgeous

Corridor Mode

Support

Backlight Compensation

Support

Penetrating Fog

Support

Interface

Signal Port

1 Photosensitive resistor,1 IR-CUT Drive   interfaceSupport Photosensitive resistor input signal   and IR-CUT infrared linkage

Smart IR Port

1

Reset Port

1 Reset signal port

Audio Port

1 Audio input,1 Audio output

Alarm Port

1 Alarm port

Video Output

1 CVBS output port

Power Port

1 DV12V power input port

USB Port

1 Reserve port

POE Port

1 POE Extensible port

Network Lamp Port

1 Network lamp

Network Port

1RJ45 10/100M Network port

Function

Motion Detection

Support setting multiple detection area,   Support setting multilevel sensitivity

Capture Function

Support JPEG capture, Max image resolution of   capturing

Safety Characteristics

Support Password protection, Watermark function

Character Superposition

Support Channel name/Date/Time superposition

Support custom title superposition

Support picture superposition

Intelligent Alarm

Support network anomaly alarm, Occluding alarm

Intelligent Function

Tripwire Testing

Storage

Support FTP Storage

Mobile Phone Client

Support Apple phone, Android phone monitoring

Support Protocols

TCP/IPUDPHTTPIGMP ICMPDHCPRTP/RTSPDNSDDNSFTPNTPPPPOEUPNPSMTPSNMP

Interface Protocols

Support ONVIF/CGI

Conventional Parameters

Power Supply

DC12V/ POE-P

Effect

Less than 1WNo IR Board

Lightning Protection

Power/Network/POE Comprehensive lightning   protection, Accord with national standard GB/T17626.5, International   standard IEC61000-4-5

Size

38*38mmSingle board
