5MP HD H.265 IR IP Camera with Audio In,Internal POE,VSS Mobile APP,Face Detection,P2P

2019-5-29 14:18:17, Visits:
Product Model: RC-BF60H-5MPO-P-A
FOB Price: US$46.77-US$48.77
Min. Order: 1pc
Product Brand: IdeaCamera
OEM/ODM: Support
Warranty: 2 Years
Country of Origin: China
Certificate: CE,FCC,ROHS

Inquire Now >

Model: RC-BF60H-5MPO-P-A

Key features:

5MP 3.6mm HD Fixed Lens (6,8,12mm optional).

Dark gray metal body with strong bracket.

Built-in 36pcs IR LEDs.

Support 30 meters IR distance.

Internal POE with audio input.

High quality network video cable with waterproof sleeve.


Main parameters:

32-bit DSP (1/2.7"OS05A10+3516D Sensor).

2560*1440@18fps High resolution.

Support Face Detection (all channels in VSS system).

Mobile APP Name (VSS Mobile).

Computer operation client (IMS300).

Support ONVIF protocol (up to 2.6).

H.265/H.264 high profile.

Support Tri-Stream technology.

Support one channel audio input, one channel audio output, support two-way voice speaking.

Support one channel alarm input, one channel alarm output.

Support one TF card interface, the maximum up to128G.

Support one electric zoom interface.

Support one 485 interface.

Support one USB interface.

Support one CVBS output.

Support SMART IR.

Support 3D DNR, DWDR.

Support P2P and cross-browser access.


Product Advantages:

Offer 2-years product warranties.

Logistics convenient.


CCC/CE/FCC Certified.

Strict product quality control.

Efficiently working with almost NVR.

Lower price.

6-8 working day per order.


Product applications:

This is the best product of safety field. It and hard disk video recorderscablepower supplydisplayetc. Constitute a complete security system. Tts application is more extensive. Such as homesfactorieshighwaysoffice buildinggardencommunity, or a large public places, etc.

5MP IP Module

Product model


System Structure


Embedded RTOS, DSP(Hi3516D)


1/2.7" CMOS sensor (OS05A10)

Video Encoding

Video Encoding

H.265 Main Profile

H.264HighProfile/ Main   Profile/ BaseLine Profile

Maximum Image Output

Main stream2560*1440@18fps;

Auxiliary stream one and two   can optional

Video Bite rate


Image Enhancement

Min. illumination

Color 0.1Lux@F1.2AGC   ON);

black and white 0.01Lux@F1.2AGC   ON

Electronic shutter

Auto1/25 to 1/10000

Day/Night switch

Auto/color/B&WBuilt-in IR_CUT


2D and 3D DNR


Support digital wide dynamic   and REAL wide dynamic

Video Adjust

Sharpness, Brightness,   Saturation, Contrast Adjustable


Signal interface

one photosensitive resistance   signal interface,

one IR_CUT drive interface

support photo resistance   signal links to IR-CUT and IR light

Smart IR

One port

Reset interface

One port

Audio interface

One audio inOne audio out

Alarm interface

One alarm in; One alarm out

electric zoom interface

One port

Power interface

One DC12V power input

CVBS Interface

One Port

USB interface

One Port

POE interface

One Extended Interface

Network lamp interface

One Port

Network interface

One RJ45 10/100M Port


Motion detection

Multiple detection zones,   variable sensitivity levels

Capture function

JPEGcapture resolution is the max   coding resolution


Password protection and water   marker


Support Channel Name and Time

Smart function

TripwireRegional invasionItems stolenItems moveDensity DetectionNumber StatThrough fenceLoitering DetectionRetrogradeFace Capture

Smart alarm

Network abnormal, cover alarm   etc.

Mobile client

VSSMOBILE for both iPhone and Android   system phone

Protocol support


Interface protocol



Power Supply


Power Consumption

<1.7W (without infrared   lamp board)

Lightning Protection

Power, network, POE all   lightning protection,

meets with standard   GB/T17626.5and IEC61000-4-5

IR_CUT pitch



38*38mmSingle Board
